RS485 ModBus stepper controller
Size NEMA8, NEMA11, NEMA14 or NEMA17 stepper controller, integrateable or stand-alone.
Controller: High-performance 32-bit processor
Driver: High-performance, high-stability driver chip
Sensor: Industrial grade 800-line magnetic encoder (accuracy depends on 32 subdivisions, i.e., 6400 steps)
Encoder: Radial magnet (absolute encoding)
Control Accuracy: 1.8 degrees + 32 subdivisions
Maximum Speed: 2000 RPM (no load)
Supply Voltage: 10V-30V
Current Adjustment: Continuously adjustable
Communication: RS485 Modbus protocol
Control Method: Pulse processing onboard, control via RS485 serial port commands
Homing Method: Photoelectric sensor/collision homing
Stall Detection: Encoder stall detection
